| Product Model | Material | Inner Diameter (mm) | Outer Diameter (mm) | Thickness (mm) | Seal Type | Precision Grade |
|---|---|---|---|---|---|---|
| 6705ZZ | GCr15 | 25 | 32 | 4 | ZZ | P5 |
| 6706ZZ | GCr15 | 30 | 37 | 4 | ZZ | P5 |
| 6805ZZ | GCr15 | 25 | 37 | 7 | ZZ | P5 |
| 6704ZZ | GCr15 | 20 | 27 | 4 | ZZ | P5 |
| 6804ZZ | GCr15 | 20 | 32 | 7 | ZZ | P5 |
| 6905ZZ | GCr15 | 25 | 42 | 9 | ZZ | P5 |
| 6806ZZ | GCr15 | 30 | 42 | 7 | ZZ | P5 |
| 6708ZZ | GCr15 | 40 | 50 | 6 | ZZ | P5 |
| 6703ZZ | GCr15 | 17 | 23 | 4 | ZZ | P5 |
| 6803ZZ | GCr15 | 17 | 26 | 5 | ZZ | P5 |
| 6904ZZ | GCr15 | 20 | 37 | 9 | ZZ | P5 |
| 6802ZZ | GCr15 | 15 | 24 | 5 | ZZ | P5 |
| 6902ZZ | GCr15 | 15 | 28 | 7 | ZZ | P5 |
| 6702ZZ | GCr15 | 15 | 21 | 4 | ZZ | P5 |
| 6004ZZ | GCr15 | 20 | 42 | 12 | ZZ | P5 |
| 6205ZZ | GCr15 | 25 | 52 | 15 | ZZ | P5 |
| 6801ZZ | GCr15 | 12 | 21 | 5 | ZZ | P5 |
| 6701ZZ | GCr15 | 12 | 18 | 4 | ZZ | P5 |
| 6901ZZ | GCr15 | 12 | 24 | 6 | ZZ | P5 |
| 6700ZZ | GCr15 | 10 | 15 | 4 | ZZ | P5 |
| 6800ZZ | GCr15 | 10 | 19 | 5 | ZZ | P5 |
| 6900ZZ | GCr15 | 10 | 22 | 6 | ZZ | P5 |
This 6706ZZ thin-section deep groove ball bearing is precision-engineered for high-performance robotic and automation applications. Manufactured in China’s leading bearing hub using premium GCr15 steel, it meets ISO and CE standards for reliability and consistency.
Key Performance Features:
- High Precision & Low Friction: Achieves tight tolerances (0.001–0.002 mm) with ultra-fine grinding and optimal clearance. Friction coefficient as low as μ ≤ 0.0012 for smooth, efficient operation.
- Compact & Lightweight: Ultra-thin 4mm width with 30mm bore and 37mm outer diameter, ideal for space-constrained robotic joints and arms.
- Durability: Hardened to HRC60 ± 2 for excellent load capacity and impact resistance. ZZ metal shields provide effective dust protection.
- Low Noise: Precision polishing delivers quiet operation (≤ 20 dB).
- Temperature Range: Stable performance from -40°C to 150°C.
Applications: Perfect for collaborative robots, robotic arms, harmonic reducers, CNC machines, and precision automation systems.
Widely trusted as a high-cost-performance alternative to imported bearings. Available for immediate shipment with OEM customization support.
This thin-section deep groove ball bearing (6706ZZ) is designed for precision robot joints. With 4mm thickness, lightweight build, high accuracy and low friction, it's ideal for collaborative robots and robotic arms. ZZ shields provide dust protection.
